Introduction

Flow often :

• Ideal fluid
• No viscosity
• Incompressible
• Not exist (to consider what will happen to an ideal fluid in a particular fluid flow problem in order to simplify the problem)

Real fluid :

• Effects of viscosity

Type of flow :

• Incompressible fluid - energy per mass, energy per volume, energy per weight
• Steady
• Uniform
• Path line
• Stream line
• Flowrate - volume flow rate (discharge), mass flow rate, weight flow rate

Equation :

• Continuity
• Bernoulli
• Euler
• Toricelli

Question 1 (Equation of Continuity)

Oil flows throw a pipe of radius, R with speed, V. some distance down the pipeline, the pipe narrow as to half its original radius. What is the speed of the oil in the narrow region of pipe?

Question 2 (Application of Bernoulli Equation)



A pressurized tank of water has a 10 cm diameter orifice at the bottom, where water discharges to the atmosphere. The water level is 10.5 m above the outlet. The tank air pressure above the water level is 350 k Pa (absolute) while the atmospheric pressure is 100 k Pa. Neglecting frictional effects, determine the initial discharges rate of water from the tank.

                                     By using bernoulli equation:-

Question 3 (Application of Momentum Equations)

A water jet srikes on a vane at 60^o. If water flows and velocity are 2 kg/s and 24.4 m/s respectively.

ρ = 1000 kg/m^{3                                    SG = 1                                        Q = 2 kg/s}

d = 2.4 m                                     β  = 60^o

v1 = 24.4 m/s                              v2 = 24.4 m/s

p1 = 200 kPa                              p2 = 200 kPa



Calculate :

a) Resultant force at stationary vane

b) Resultant force at vane if the vane moving at velocity 8.9 m/s in jet direction



Direction x ;

Direction y ;







Conclusion

• The equations that we learn can be used to calculate the rate of flow, Q, head loss for wall and pipe friction.
• The bernoulli equation used to calculate the value of velocity in the pipe.
• Understand that the continuity equation come from the equation V = Q/A.
• We also know how to use the momentum equation in related questions.
• Know how to calculate the resultant force at stationary and moving vane by resolve at x and y axis.
• Understand more about the concepts of basic equation in fluid mechanics.

•
